JBL JBLMARSPKST6GRYAM 6.5" Stage Marine Speakers

The JBL JBLMARSPKST6GRYAM Stage Marine 6 speakers are a gray 6-1/2-inch, two-way marine speaker pair designed for boat audio systems. They provide a direct way to replace weather-worn factory speakers or build an outdoor-capable sound system for a boat. Each speaker is rated for 60 watts RMS and uses a 4-ohm nominal impedance.

Open-water listening brings wind, engine noise, and little acoustic reinforcement, so these speakers are tuned for outdoor use. Their 90 dB sensitivity and 60 Hz to 20 kHz frequency response support clear, full-range playback from a compatible marine stereo or amplifier. A grille-mounted 1/2-inch balanced dome tweeter handles high-frequency detail while the woofer covers the main musical range.

The Stage Marine 6 is built for locations exposed to spray and sunlight. JBL specifies an IPX5 marine rating, a one-piece polymer basket, rubber surround, and weather-resistant tweeter construction. The grille-mounted tweeter design also helps protect the front of the woofer cone from water intrusion.

These speakers use sealed polypropylene cones and attached gray grilles for a clean, integrated appearance. Their 7-5/64-inch outside diameter, 5-1/32-inch cutout requirement, and 2-3/4-inch mounting depth provide the key measurements needed when replacing existing 6.5-inch marine speakers. Stainless-steel mounting hardware and a foam gasket are included for installation.

Use a pair as the main full-range speakers in a compact marine audio system, or combine multiple pairs with a compatible marine receiver and amplifier for broader boat coverage. JBL includes two speaker pigtail harnesses to support the connection process. For system matching, provide each speaker with an amplifier channel rated appropriately for its 60-watt RMS power handling at 4 ohms.

Key Features

• 6.5-Inch Two-Way Design: Combines a woofer and 1/2-inch tweeter for full-range marine playback.
• 60W RMS Power Handling: Supports properly matched marine stereo or amplifier power.
• IPX5 Marine Rating: Built for exposure to water spray in marine environments.
• Balanced Dome Tweeter: Grille-mounted tweeter supports clear high-frequency reproduction.
• Polymer and Rubber Construction: One-piece polymer basket and rubber surround support outdoor durability.
• Gray Attached Grilles: Provides a coordinated marine-ready appearance without separate grille fitting.

Design & Installation

The JBLMARSPKST6GRYAM uses a one-piece polymer basket, sealed polypropylene cone, rubber surround, weather-resistant balanced dome tweeter, and UV-resistant gray grille. Its grille-mounted tweeter is positioned above the woofer cone, helping reduce the path for water intrusion. The speaker is specified for IPX5-rated marine use and is intended for exposed boat-audio locations.

Confirm a 5-1/32-inch mounting cutout and at least 2-3/4 inches of mounting depth before installation; the outside diameter is 7-5/64 inches. The package includes a foam gasket, stainless-steel mounting hardware, a drill bit, and two pigtail harnesses. Connect each speaker to a compatible 4-ohm marine receiver or amplifier, observe polarity, and use the included gasket when mounting to help create a proper seal.
